Product Center
24FE(PoE)+1G Combo+1GE PoE Switch
Model NO：PT5030FBS-V3
PT5030FBS-V3 has 24*10/100Mbps adaptive RJ45 ports, and the uplink ports are 1*1000Mbps Combo port and 1*10/100/1000Mbps RJ45 port, each RJ45 port supports MDI/MDIX auto-flip and wire speed forwarding function. Among them, ports 1-24 have PoE power supply function and support IEEE802.3af/at standard, which can be used as Power over Ethernet devices and can automatically detect and identify the powered devices that meet the standard and supply power to them through the network cable.
Product features
- Supports the IEEE802.3af/at standard;
- Single PoE port output power up to 30W;
- Supports port overload protection, short circuit protection, PoE port priority;
- Data transmission and power supply distance guaranteed to 100m;
- Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control;
- Provides VLAN isolation, CCTV network extension, PD-ALIVE dropped self-connection, SCP Network Storm Suppression four dialing modes, which can be freely combined to turn on, VLAN isolation and CCTV network extension are standard modes when they are turned off, and CCTV;
- Panel indicators monitor operating status and help with fault analysis;
- PoE, motherboard, power supply are all in one PCBA Board.
Product Overview
PT5030FBS-V3 has 24*10/100Mbps adaptive RJ45 ports, and the uplink ports are 1*1000Mbps Combo port and 1*10/100/1000Mbps RJ45 port, each RJ45 port supports MDI/MDIX auto-flip and wire speed forwarding function. Among them, ports 1-24 have PoE power supply function and support IEEE802.3af/at standard, which can be used as Power over Ethernet devices and can automatically detect and identify the powered devices that meet the standard and supply power to them through the network cable.11-inch standard rack mount, plug-and-play, no management required Dynamic LED indicator to provide simple working status indication and troubleshooting Supports four dialing modes that users can choose to turn on or off depending on the application environment.
Product Features
- Supports the IEEE802.3af/at standard;
- Single PoE port output power up to 30W;
- Supports port overload protection, short circuit protection, PoE port priority;
- Data transmission and power supply distance guaranteed to 100m;
- Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control;
- Provides VLAN isolation, CCTV network extension, PD-ALIVE dropped self-connection, SCP Network Storm Suppression four dialing modes, which can be freely combined to turn on, VLAN isolation and CCTV network extension are standard modes when they are turned off, and CCTV;
- Panel indicators monitor operating status and help with fault analysis;
- PoE, motherboard, power supply are all in one PCBA Board.
Ordering information
| Model | PT5020FBS-V3 |
| PT5030FBS-V3 | 24FE(PoE)+1G Combo+1GE PoE Switch |
| Packaging Accessories |
Power Cord *1 Feet *4 Rack Mount Kit *2 Screw *8 User Manual *1 |
